Powered line array cabinet with network audio
WL-DAL210 combines active amplification, AES67-compatible Dante audio, analog backup, FIR processing, and onboard DSP in one loudspeaker platform.
Professional Audio
WL-DAL210 Active Line Array Speaker
HUSHAN
WL-DAL210
¥4,899.00
Active line array loudspeaker with analog/digital backup, AES67-compatible Dante networking, FIR processing, onboard DSP, 700W rated power, and remote monitoring for professional sound reinforcement.
Product documents available on request
Support scope confirmed for each order
Technical Specifications
| Type | 2-way active line array element |
| LF Driver | 2 x 8 inch neodymium woofer |
| HF Driver | 1 x 3 inch neodymium compression driver |
| Frequency Response | 65 Hz - 20 kHz |
| Max SPL | 138 dB peak |
| Coverage | 100 deg H x 10 deg V |
| Amplifier | LF 800W + HF 400W Class-D |
| Digital Audio | Dante / AES67, 48 kHz / 24-bit |
| Analog Backup | XLR input, auto failover <200 ms |
| Network | 2 x RJ45 Dante + 1 x RJ45 Control |
| Power | 100-240 VAC, PowerCON TRUE1 in/out |
| Rigging | Integrated 3-point flyware, 0-12 deg splay |
| Dimensions | 580 x 260 x 410 mm |
| Weight | 22 kg |
Professional Audio
Active Line Array with Analog and Digital Backup
WL-DAL210 combines a powered line-array cabinet, AES67-compatible Dante networking, analog backup, FIR processing, and remote monitoring for venues that need reliable high-output sound reinforcement with modern network control.
More resilience with fewer external boxes
Digital and analog signal paths, presets, PC software, and IoT monitoring help integrators reduce rack complexity while keeping venue audio reliable.
Auditoriums, theaters, halls, touring systems
Use it for venues that need focused coverage, high SPL, repeatable setup, and remote system monitoring.
700 W
Rated Active Power
128 dB
Continuous SPL
90 x 10
Coverage
34 kg
Net Weight
Analog and digital backup
The loudspeaker supports automatic, analog-only, and digital-only operating modes, helping the system keep audio running when network or analog paths change.
AES67-compatible Dante audio
Digital audio over RJ45 simplifies signal routing and supports modern networked AV system architecture.
FIR-based processing
Built-in FIR processing and a 1-in/2-out processor provide gain, delay, phase, EQ, compressor, limiter, and crossover control.
700W active power section
Integrated amplification drives dual 10-inch low-frequency drivers and one 3-inch high-frequency driver without separate amplifier racks.
25 preset memories
Configuration files can be imported and exported, with onboard preset storage for repeatable venue deployments.
IoT remote monitoring
PC software and web-based platform control can monitor DSP status, amplifier status, and device operation across LAN or public network connections.
Venue System
Line Array Performance for Installed and Touring Spaces
WL-DAL210 fits projects where analog backup, network audio, FIR processing, presets, and remote monitoring need to live inside one active loudspeaker platform.
Venue Deployment
Networked Audio for Large Rooms and Performance Spaces
With Dante/AES67-compatible digital input, analog backup, and remote status monitoring, WL-DAL210 is suited for theaters, multipurpose halls, auditoriums, and touring-style systems that still need predictable setup and control.
Rear Control and I/O
Built for Integrators, Not Just Operators
The cabinet includes XLR analog connections, RJ45 network audio/control ports, RS485, display and rotary control, power input/output, firmware update support, default recovery, and parameter locking for managed installations.
System Flow
How WL-DAL210 Fits a Sound Reinforcement Project
Model the room
Plan coverage for seating depth, balcony geometry, and stage position.
Route audio paths
Use AES67-compatible Dante digital audio with analog backup for resilience.
Tune onboard DSP
Set gain, delay, phase, EQ, compressor, limiter, and crossover parameters.
Monitor remotely
Use PC software or IoT web management to check DSP and amplifier status.
Applications
Where It Performs
Auditoriums and theaters
Focused 90 x 10 degree coverage and high SPL support speech and program audio in wide seating areas.
Multipurpose halls
Preset recall and remote monitoring help teams adapt the system for conferences, shows, and ceremonies.
Rental and project systems
Analog/digital backup and onboard DSP reduce the need for extra processing racks in temporary or semi-permanent setups.
Power and drivers
700W rated active cabinet with 10-inch x 2 LF and 3-inch x 1 HF drivers.
Network audio
AES67-compatible Dante digital audio is listed in the source data.
Physical size
296.8 x 780 x 428 mm, 34 kg net weight.
